| W x D x H |
181/8" x 267/8" x 243/8"
|
| Weight |
148 lb
|
| Power Input Type | Electric |
| Primary Power Input | 230 V x 50 Hz x 1 PH |
| Certifications |
![]() ![]() |
Merrychef conneX®16
The largest cavity, with the smallest footprint. For the most food in the quickest time.
The next generation of high speed ovens, Merrychef conneX®16 has the largest cavity (16” x 16”) to smallest oven width (18”) of any high speed oven on the market. A space-saving unit that doesn’t compromise on speed or capacity, delivering food up to 80% faster than conventional cooking methods. The larger cavity allows you to deliver, consistent high quality food on demand as well as the flexibility to speedily ‘batch’ cook to hold popular food items, and manage fluctuations in demand, avoiding queues.
A highly aesthetic design for front-of-house, the conneX®16 features a high definition 7” operating screen in a robust glass surround and showcases the new easyTouch® 2.0 software. The conneX range delivers the most intuitive operating controller, it works just like a mobile phone, and along with over 100 pre-programmed recipes, operators are very quickly able to deliver consistent, delicious results with every order.
Born connected, the conneX® range comes with Wi-fi and ethernet connectivity as standard, and offers free subscription for the first 12 months after purchase, to the industry leading Welbilt KitchenConnect® platform enabling the ovens to be monitored and menus to be updated remotely.
Like all Merrychef high speed ovens the new Merrychef conneX® 16 is easy to install, ventless, operates quietly, has cool-to-touch exterior, quick pre-heat and cool down times, low energy usage in standby, providing unbeatable value for money.
| The conneX®16 is the most versatile, high speed oven on the market. |
| An all-in-one unit ideally suited to rapidly cook, toast, grill, and reheat fresh or frozen food, eliminating the need for other appliances. |
| Cooking up to 20x faster than other cooking methods. |
| It has the largest cavity 41.3cm x 41.3cm (16” x 16”) to oven width 45.8cm (18”) ratio, and fits on a 700mm worktop, perfect when space is at a premium. |
| Suitable for front-of-house, operating quietly and easy to install due to ventless cooking capabilities through a built-in catalytic converter, eliminates the need for an extraction fan. |
| Cool to touch exterior makes it safe to locate anywhere with no need to allow space around the unit. |
| 7” HD widescreen display and new generation easyTouch®2.0, icon driven controller. |
| Easy to operate with a 7” HD widescreen display and new generation easyTouch®2.0, icon driven controller, ensuring consistent, high quality dishes. |
| Stainless steel cavity and casework, with a sealed rounded edged cavity makes it easy to clean. |
| Patented easy access front mounted monitored air filter. |
| WiFi/ethernet connected with access to KitchenConnect cloud for easy menu updates (or via a USB memory stick). |
conneX®16 High Power
Full size cooking tray (Black)
Part Number: 32Z4175H15 x W353 x D353 mm
Full size cooking mesh tray
Part Number: 32Z4176H19 x W353 x D 353 mm
Non-stick cooking liner (Natural)
Part Number: 32Z4178W386 x D386 mm
Flat cook plate
Part Number: DF0035H6 x W400 x D400 mm
Paddle with hand guard and sides
Part Number: SF326W400 x D398 mm
Cool down pan
Part Number: 32Z40281/2 size 100 mm deep
9x square mould
Part Number: 32Z4196H23.5 x W346 x D295 mm
Half size deep cooking tray (Green)
Part Number: 32Z4179H25 x W195 x D391 mm
Half size deep cooking tray (Black)
Part Number: 32Z4185H25 x W195 x D391 mm
Griddled cook plate
Part Number: DF0127H6 x W400 x D400 mm
Full size deep cooking tray (Black)
Part Number: 32Z4152H25 x W393 x D393 mm
Full size deep cooking tray (Green)
Part Number: 32Z4167H25 x W393 x D393 mm
Non-stick cooking liner (Green)
Part Number: 32Z4151W386x D386 mm
conneX 16 Low opening Panini Press with flat bottom plate
Part Number: PSF187
conneX 16 High opening Panini Press with flat bottom plate
Part Number: PSF189
